How much line should you let out when jigging? Start with the depth of the fish layer, not simply the distance to the bottom. Jigging line length is not the same as vertical lure depth: current, boat drift, line angle and underwater bow all affect where your jig travels.
This guide explains how to estimate jigging depth, use a simplified line-angle calculation and choose relevant jigging equipment without treating line-out readings as exact depth measurements.
Quick answer: line length versus jig depth
With a nearly vertical line, the underwater line length can be a useful starting estimate of depth. As the line angles away or bows in current, that estimate becomes less reliable. A line counter or marked braided fishing line measures line paid out, not the jig's exact position.
Identify the fish layer before calculating line out
Separate bottom depth from the fish marks you want to investigate. If the sounder shows bottom at 80m and marks between 45m and 55m, that shallower band is the initial target. Sonar marks do not prove species, feeding activity or an immediate bite.
How to calculate fish depth from height above bottom
Using the same reference and units, target depth = bottom depth − height above bottom. A layer 20m above an 80m bottom is about 60m below that reference. If the display already gives fish depth, use that as the starting estimate instead.
Check the reference level and units
A sounder can be configured relative to the transducer, surface or another offset. Check its settings and instructions. A line counter has its own reference. Account for line above water and any leader excluded from the measurement, and keep metres and feet consistent.
Jigging depth calculation: a simplified line-angle model
For an ideal straight underwater line of length L at angle θ from vertical, vertical projection is D = L × cos(θ). Rearranging gives L = D ÷ cos(θ).
For example, 60m of straight underwater line at 30 degrees from vertical projects about 52m vertically. A 60m vertical projection at that ideal angle requires about 69.3m of underwater line. These are geometry examples, not fixed extra-line instructions.
Current curves the line. Its visible surface angle does not describe every section below, so this model cannot precisely locate a real jig. Do not keep paying out line to force the calculation to work: additional line may increase bow and reduce control.
Using marked braided line, line counters and handle turns
Verify a line's documented marking intervals rather than assuming every color change means a particular distance. Marks measure line, not vertical depth. Cuts, respooling and leader changes affect the reference. Do not apply markers or solvents without manufacturer approval.
Calibrate counters according to their instructions. A calibrated line-out reading still does not compensate automatically for bow or drift. Reel pickup changes with spool fill, and gear ratio alone does not provide distance per turn.
Relevant GOOFISH jigging reels and braided fishing line
Abyss Jigger Gen 2 jigging reel
The GOOFISH Abyss Jigger Gen 2 jigging reel is relevant when selecting a manual reel for vertical jigging. Choose the correct left- or right-hand version and check the listed line capacity against your intended setup. Reel retrieve figures are not a constant ruler and do not establish a built-in depth counter.
Max-8 braided fishing line
Compare the available options for GOOFISH Max-8 braided fishing line when planning your jigging setup. Package length is not capacity on a particular reel. This guide does not establish calibrated color intervals for Max-8; the illustrated equipment is generic. Do not infer PE class or diameter from nominal strength alone.
A practical vertical-jigging depth-control workflow
- Check units, sounder reference and current target-layer readings.
- Choose suitable line capacity and a jig within the rod's intended range.
- Track approximate line out during controlled deployment.
- Observe drift, line direction and available sonar information.
- Retrieve to reassess when control deteriorates.
Do not drop to bottom merely to establish a reference for suspended fish. Bottom contact adds snag risk and does not prove the jig is beneath the transducer. No depth alone prescribes jig mass or working drag.
Avoid high-sticking, locked-spool pulling and forceful snag-clearing sweeps. Never wrap loaded braid around a hand. Inspect line, leader, knots and guide inserts after suspected damage.
Frequently asked questions about jigging line length
Does 60m of line out mean a jig at 60m?
Not necessarily. Offsets, angled line and underwater bow affect the relationship between line length and jig depth.
Should fish height be added to bottom depth?
No. Subtract height above bottom using a shared reference. For example, fish 20m above an 80m bottom are approximately 60m deep relative to that reference.
Can the visible line angle give exact depth?
No. Straight-line geometry is a simplified model, and the surface angle does not reveal the full underwater curve.
Is reel gear ratio enough to calculate line retrieved?
No. Gear ratio alone does not establish distance per handle turn, and pickup changes with spool fill.
The takeaway: identify the fish layer, align reference levels and treat jigging line-length measurements as estimates. Observe and recheck instead of relying on one formula.
